Used Fluid Metering FMI QV Lab Pump with RH1CTC Pump Head

Variable-Speed Valveless Piston Pump for High-Precision Metering (Up to 576 mL/min)

Achieve exceptional fluid control and tight volumetric accuracy without overextending your laboratory or pilot plant budget. The pre-owned Fluid Metering (FMI) QV Variable-Speed Valveless Piston Pump, paired with the highly advanced RH1CTC RH Series Pump Head, delivers precise, repeatable flow control for demanding analytical and OEM process applications.

By sourcing this fully tested, used FMI metering system through HiTechTrader, research facilities and process engineers can secure highly accurate, pulsation-free metering for chemical dosing, chromatography support, and automated process control at a fraction of the cost of buying new.

Condition & Unit Details

• Condition: Fully inspected, used variable-speed metering pump in excellent working condition.

• Testing: Powered on, variable-speed drive and stroke adjustment mechanisms fully tested for smooth, bidirectional operation by our technicians.

• Included Components: FMI QV Variable-Speed Drive module and RH1CTC Ceramic Pump Head.

• The HiTechTrader Guarantee: Backed by our standard 30-day limited warranty. We have been a trusted provider of high-quality used laboratory and scientific equipment since 1982.

CeramPump Valveless Technology for Precise Metering

Traditional metering pumps rely on check valves that are prone to clogging, sticking, or failing over millions of cycles. Based on FMI’s proprietary CeramPump® valveless piston principle, this system offers accurate positive displacement metering with only one moving component in the fluid path.

This elegant design minimizes mechanical drift and drastically reduces maintenance requirements. Because the pump is reversible, it supports bidirectional metering without the need for check valves or complex bypass lines, maintaining stable performance even during continuous high-cycle dosing.

RH1CTC Ceramic Pump Head Performance

The RH1CTC head belongs to the elite RH pump head family, which utilizes a completely nonmetallic ceramic (or zirconia) piston and matching ceramic cylinder liner. This provides exceptional wear resistance and tight volumetric control, delivering a highly stable performance with a Coefficient of Variation (CV) of ≤0.5% for repetitive dispensing.

With the QV drive’s variable speed and a fully adjustable stroke length (from 0 to 100%), operators can seamlessly tune flow from microliters per minute up to robust transfer rates. When operating at full stroke and rated maximum speed, this 1/4-inch piston configuration delivers a maximum flow rate of up to approximately 576 mL/min.

Extreme Chemical Compatibility & OEM Integration

Equipped with chemically resistant casing materials such as PVDF, ETFE, or polypropylene, the RH1CTC head provides broad compatibility with aggressive industrial chemicals and high-purity fluids. Furthermore, the compact 1/4-inch shaft design makes mechanical integration straightforward, ensuring this pump is ready to be dropped into OEM analyzers, automated chromatography systems, and pilot plant skids.

Technical Specifications

• Manufacturer: Fluid Metering, Inc. (FMI)

• Pump Model: QV Laboratory / OEM Variable-Speed Pump Drive

• Pump Type: Valveless Positive Displacement Piston Pump (CeramPump design)

• Pump Head Model: RH1CTC (RH Series)

• Shaft Size: 1/4-inch diameter shaft

• Maximum Flow Rate: Up to approx. 576 mL/min (at full stroke/max speed)

• Piston & Cylinder: Ceramic or zirconia piston with ceramic cylinder liner

• Casing Material: PVDF, ETFE, or polypropylene (depending on specific variant)

• Inlet/Outlet Connections: Typically 1/4" OD tubing or 1/4-28 female ports

• Operating Temperature: 0–100 °C (32–212 °F) for PVDF/ETFE casings

• Maximum Pressure: Up to 100 psig

• Flow Adjustment: Stroke adjustable from 0–100% plus variable speed control

• Flow Direction: Reversible / bidirectional metering

• Dispense Repeatability: Coefficient of variation (CV) ≤0.5%

Nationwide Shipping & Availability

Waiting on long OEM lead times for high-precision metering pumps can stall critical process development. Operating out of our primary facility in Coatesville, Pennsylvania, HiTechTrader provides rapid, secure shipping to research institutions, pharmaceutical labs, and industrial pilot plants nationwide.

Whether your facility is located locally on the East Coast, in major tech and biotech hubs like California, or anywhere across the globe, we ensure your used fluid processing equipment arrives safely and ready for immediate deployment.

Frequently Asked Questions (FAQ)

What is the maximum flow rate of the FMI QV pump with the RH1CTC head? When operating at full stroke and rated maximum speed, this specific configuration (utilizing the 1/4-inch piston RH head) can achieve a maximum flow rate of up to approximately 576 mL/min.

What fluids can the RH1CTC pump head handle? The RH1CTC pump head is designed for broad chemical compatibility. It features a completely nonmetallic fluid path consisting of a ceramic piston and cylinder liner, housed in a highly resistant PVDF, ETFE, or polypropylene casing. This makes it ideal for safely handling aggressive industrial solvents, harsh acids, and high-purity laboratory fluids.

How accurate is the FMI CeramPump design? The CeramPump design is exceptionally accurate for both continuous metering and batch dosing. Because it uses a valveless positive displacement mechanism with a precision ceramic piston, it eliminates the inconsistencies caused by sticking check valves, achieving a remarkable Coefficient of Variation (CV) of ≤0.5% for repetitive dispensing.

Buy the Used FMI QV Lab Pump with RH1CTC Head

HiTechTrader offers the pre-owned Fluid Metering FMI QV Variable-Speed Valveless Piston Pump with the RH1CTC RH Series Pump Head, providing laboratories and industrial facilities with a highly durable, precision solution for fluid dosing.

Contact HiTechTrader today to:

• Request pricing

• Confirm exact casing materials, port connections, and tubing compatibility

• Discuss expedited shipping options to minimize your lab's downtime
