Parr Horizontal Reactor 2 Gallon Inconel

Parr Horizontal Reactor – 2 Gallon Inconel 600 Vessel

The Parr Horizontal Reactor with a 2-gallon (7.57 L) Inconel 600 vessel is built for advanced high-temperature and high-pressure chemical processing. Engineered with a horizontal orientation, this reactor is specifically designed to handle challenging biomass conversion, fibrous feedstocks, and viscous reaction mixtures with unmatched efficiency. Its Inconel 600 alloy construction provides superior resistance to corrosion and oxidation, making it an excellent solution for laboratories and pilot plants tackling aggressive reaction environments.

At HiTechTrader, we provide fully tested Parr reactors that combine durability, precision, and cost-effectiveness. This horizontal unit is not only robust enough for heavy-duty research but also versatile, offering reliable performance across a range of chemical and biofuel applications. Every reactor we deliver undergoes thorough inspection and validation, ensuring researchers have a dependable tool for their most demanding projects.

Vessel and Construction

1. Capacity: 2 gallons (7.57 liters)
2. Material: Inconel 600 alloy for exceptional corrosion and thermal resistance
3. Design: Horizontal stirred vessel, optimized for fibrous or viscous materials
4. Sight Glass: Rated to 26 bar (377 psi) and 250 °C when installed
5. Optional Ratings: Higher temperature/pressure capacities available without sight glass
6. Finish: Rugged surface treatment for demanding chemical conditions

Closure and Sealing

1. Secure high-pressure vessel closure system
2. Sight glass enables visual reaction monitoring
3. Tilting mechanism for easy loading, unloading, and discharge

Operating Parameters

1. Maximum Pressure: 26 bar (377 psi) with sight glass
2. Maximum Temperature: 250 °C with sight glass
3. Heating: Integrated heater with precise temperature control
4. Mixing: Heavy-duty motor with double-anchor stirrers for thorough agitation

Accessory Compatibility

1. Fully compatible with the Parr 4848 Reactor Controller for real-time monitoring
2. Customizable with alternative stirrer designs, automated controls, or additional ports
3. Optional cooling coils and manifold connections for greater process flexibility

Safe Operation Guidelines

1. Secure tilting and inversion features before operation
2. Maintain operation within rated limits when using sight glass
3. Inspect stirrer seals and fittings regularly
4. Follow Parr's official SOPs for all high-pressure systems

Applications

1. Biomass conversion and cellulosic material processing
2. Biofuel and biochemical pilot-scale research
3. High-temperature synthesis in corrosive environments
4. Specialty chemical production with viscous or solid-liquid mixtures
5. Research projects where horizontal vessel geometry is advantageous

Why Buy from HiTechTrader?

At HiTechTrader, we specialize in delivering refurbished Parr horizontal reactors that offer both cost savings and proven reliability. Each system is carefully inspected, performance-tested, and supported by decades of expertise in high-pressure reactor technology. For laboratories engaged in biomass research, specialty chemical production, or advanced pilot studies, our reactors provide a corrosion-resistant, durable solution without the premium cost of brand-new equipment. With HiTechTrader, you gain trusted performance and lasting value.
