Carbolite Gero HTR Spinning Tube Furnace
Manufactured by Carbolite Gero this laboratory scale rotating tube reactor furnace has a high temperature range of 1100 C. 50ml chamber reaction capacity.
Specifications for HTR 11/75
- Max temp (°C) 1100
- Heat-up time (mins) 11
- Max continuous operating temp (°C) 1000
- Cooling time with lid open (mins) 15
- Dimensions: Reaction chamber dimensions (mm) 75 x 100
- Dimensions: Reaction chamber capacity (ml) 50
- Dimensions: Oscillation frequency per min 1 to 8
- Dimensions: Rotation in each direction 315°
- Dimensions: External H x W x D (in) lid open 19 x 45 x 22
- Dimensions: External H x W x D (in) lid down 32 x 45 x 27
- Max power (W) 1500
- Holding power (W) 400
- Thermocouple type K
- Weight 88 Lbs
